    *IGrid SV IV 16.8KW = 3X IGrid SV IV 5.6KW +3X Parallel Kit

    Main Features:

    • Customizable status LED ring with RGB lights
    • Touchable button with 4.3" colored LCD
    • Supports USB On-the-Go function
    • Data log events stored in the inverter
    • Self-consumption and Feed-in to the grid
    • Programmable supply priority for PV, Battery or Grid
    • User-adjustable charging current and voltage
    • Programmable multiple operationmodes:Grid-tie,off-gridand

    grid-tie with backup

    • Built-in Wi-Fi for mobile monitoring (App is available)
    • Reserved communication port for BMS
    • Parallel operation up to 9 units

    MODEL

    IGridSV-IV-5.6KW

    PHASE

    1-phasein/1-phaseout

    MAXIMUMPVINPUTPOWER

    6000W

    RATEDOUTPUTPOWER

    5600W

    MAXIMUMCHARGINGPOWER

    6000W

    GRID-TIEOPERATION

    PVINPUT(DC)

    NominalDCVoltage

    MaximumDCVoltage

    360VDC/450VDC

    Start-upVoltage

    InitialFeedingVoltage

    110VDC/120VDC

    MPPVoltageRange

    120VDC~430VDC

    NumberofMPPTrackers

    MaximumInputCurrent

    1/27A

    GRIDOUTPUT(AC)

    NominalOutputVoltage

    220/230/240VAC

    OutputVoltageRange

    184-264.5VACor195.5-253VAC(Selectable)

    NominalOutputCurrent

    24.3A

    PowerFactor

    >0.9

    EFFICIENCY

    Maximum ConversionEffciency(DC/AC)

    96%

    OFF-GRIDOPERATION

    ACINPUT

    ACStart-upVoltage

    AutoRestartVoltage

    120-140VAC/180VAC

    AcceptableInputVoltageRange

    90-280VACor170-280VAC

    MaximumACInputCurrent

    40A

    PVINPUT(DC)

    MaximumDCVoltage

    450VDC

    MPPVoltageRange

    120VDC~430VDC

    NumberofMPPTrackers

    MaximumInputCurrent

    1/27A

    BATTERYMODEOUTPUT(AC)

    NominalOutputVoltage

    220/230/240VAC

    OutputWaveform

    Puresinewave

    Efficiency(DCtoAC)

    93%

    HYBRIDOPERATION

    PVINPUT(DC)

    NominalDCVoltage

    MaximumDCVoltage

    360VDC/450VDC

    Start-upVoltage

    InitialFeedingVoltage

    110VDC/120VDC

    MPPVoltageRange

    120VDC~430VDC

    NumberofMPPTrackers

    MaximumInputCurrent

    1/27A

    GRIDOUTPUT(AC)

    NominalOutputVoltage

    220/230/240VAC

    OutputVoltageRange

    184-264.5VACor195.5-253VAC(Selectable)

    NominalOutputCurrent

    24.3A

    ACINPUT

    ACStart-upVoltage

    AutoRestartVoltage

    120-140VAC/180VAC

    AcceptableInputVoltageRange

    90-280VACor170-280VAC

    MaximumACInputCurrent

    40A

    BATTERYMODEOUTPUT(AC)

    NominalOutputVoltage

    220/230/240VAC

    Efficiency(DCtoAC)

    93%

    BATTERY&CHARGER

    NominalDCVoltage

    48VDC

    MaximumSolarChargingCurrent

    120A

    MaximumACChargingCurrent

    120A

    MaximumChargingCurrent

    120A

    GENERAL

    PHYSICAL

    Dimension,DxWxH(mm)

    140x295x468

    NetWeight(kgs)

    12

    INTERACE

    ParallelFunction

    Yes,9units

    CommunicationPort

    USB/RS232/RS485/WIFI/Dry-contact

    ENVIRONMENT

    Humidity

    0~90%RH(Non-condensing)

    OperatingTemperature

    -10to50ºC
