    2023 New Design Hybrid Solar Inverter 5.6KW 450Vdc PV 100A MPPT Parallel Inverter 230V 48V Pure Sine Wave Hybrid Inverter Battery Charger Ship From EU

    5.6KW 450Vdc 100A MPPT Parallel Inverter
    Save $164
    $91600
    $1,08000
    Free EU shipping
    Free returns
    Carbon neutral
    Secure payments
    Color
    Germany
    Quantity
    Only 30 left

    Checkout Securely With

    Authentic guarantee

    12 months warranty

    Fast return and exchange

    Technical support

    EASUN POWER Solar Inverter 5.6KW 450Vdc PV 100A MPPT Parallel Inverter 230V 48V Pure Sine Wave Hybrid Inverter Battery Charger
    · Max.can be 9 pcs in parallel with optional kit
    · Efficiently work with or without battery
    · MPPT Solar Charge Controller up to 6000W solar panel
    · Built - in Wifi for mobile monitoring (Requires APP)

    · Compatible with (Li-ion,LiFePo4 and etc.) batteries
    · Battery Equalization

    Model

    IGrid-VX-IV-5.6KW-Wifi

    Battery Input

    Battery type

    Sealed、FLood、GEL、LFP、Ternary

    Rated Battery Input Voltage

    48V ( Minimum Startup Voltage 44V)

    Hybrid Charging Maximum

    Charging Current

    100A



    Battery Voltage Range

    40Vdc~60Vdc ± 0.6Vdc(Undervoltage Warning/Shutdown Voltage/ Overvoltage Warning/Overvoltage Recovery...)

    Solar Input

    Maximum PV Open-circuit Voltage

    500Vdc

    PV Working Voltage Range

    120-500Vdc

    MPPT Voltage Range

    120-450Vdc

    Maximum PV Input Current

    22A

    Maximum PV Input Power

    6000W

    Maximum PV Charging Current

    100A

    AC Input(generator/grid)

    Mains Maximum Charging Current

    60A

    Rated Input Voltage

    220/230Vac

    Input Voltage Range

    UPS Mains Mode:(170Vac~280Vac)土2% APL Generator Mode:(90Vac~280Vac)±2%

    Frequency

    50Hz/ 60Hz (Automatic Detection)

    Mains Charging Efficiency

    >95%

    Switch Time (bypass and inverter)

    10ms(Typical Value)

    Maximum Bypass Overload Current

    40A

    AC Output(Backup power)

    Output Voltage Waveform

    Pure Sine Wave

    Rated Output Voltage (Vac)

    230Vac

    Rated Output Power (VA)

    5600

    Rated Output Power(W)

    5600

    Peak Power

    10000VA

    On-load Motor Capacity

    4HP

    Output Frequency Range(Hz)

    50Hz±0.3Hz/60Hz±0.3Hz

    Maximum Efficiency

    >92%

    No-load Loss

    Non Energy-saving Mode: ≤50W Energy-saving Mode:≤25W (Manual Setup)

    AC Output(Grid)

    Rated Output Power (VA)

    5600

    Max. apparent power (VA)

    5600

    Max. output current (A)

    24

    THDI

    <3%

    Rated voltage(V)

    230Vac

    Frequency

    50Hz/60Hz

    General

    Number of parallel

    1-6PCS

    Certificate

    CE(IEC62109-1)/CETL(UL 1741 C22.2 NO.107.1)/FCC/SAA

    EMC Certification Level

    EN61000, C2

    Working Temperature Range

    -10°C ~ 55°C

    Storage Temperature Range

    -25°C ~ 60°C

    Humidity Range

    5% to 95%(Conformal Coating Protection)

    Dimensions

    426mm*322mm*124mm

    Weight (KG)

    10.5
