Main Features:
- Customizable status LED ring with RGB lights
- Touchable button with 4.3" colored LCD
- Supports USB On-the-Go function
- Data log events stored in the inverter
- Self-consumption and Feed-in to the grid
- Programmable supply priority for PV, Battery or Grid
- User-adjustable charging current and voltage
- Programmable multiple operationmodes:Grid-tie,off-gridand
grid-tie with backup
- Built-in Wi-Fi for mobile monitoring (App is available)
- Reserved communication port for BMS
- Parallel operation up to 9 units 2units parallel to IGRID-SV-IV-11.2KW 3 units parallel to IGRID-SV-IV-16.8kw
|
MODEL |
IGridSV-IV5.6KW |
|
PHASE |
1-phasein/1-phaseout |
|
MAXIMUMPVINPUTPOWER |
6000W |
|
RATEDOUTPUTPOWER |
5600W |
|
MAXIMUMCHARGINGPOWER |
6000W |
|
GRID-TIEOPERATION |
|
|
PVINPUT(DC) |
|
|
NominalDCVoltage MaximumDCVoltage |
360VDC/450VDC |
|
Start-upVoltage InitialFeedingVoltage |
110VDC/120VDC |
|
MPPVoltageRange |
120VDC~430VDC |
|
NumberofMPPTrackers MaximumInputCurrent |
1/27A |
|
GRIDOUTPUT(AC) |
|
|
NominalOutputVoltage |
220/230/240VAC |
|
OutputVoltageRange |
184-264.5VACor195.5-253VAC(Selectable) |
|
NominalOutputCurrent |
24.3A |
|
PowerFactor |
>0.9 |
|
EFFICIENCY |
|
|
Maximum ConversionEffciency(DC/AC) |
96% |
|
OFF-GRIDOPERATION |
|
|
ACINPUT |
|
|
ACStart-upVoltage AutoRestartVoltage |
120-140VAC/180VAC |
|
AcceptableInputVoltageRange |
90-280VACor170-280VAC |
|
MaximumACInputCurrent |
40A |
|
PVINPUT(DC) |
|
|
MaximumDCVoltage |
450VDC |
|
MPPVoltageRange |
120VDC~430VDC |
|
NumberofMPPTrackers MaximumInputCurrent |
1/27A |
|
BATTERYMODEOUTPUT(AC) |
|
|
NominalOutputVoltage |
220/230/240VAC |
|
OutputWaveform |
Puresinewave |
|
Efficiency(DCtoAC) |
93% |
|
HYBRIDOPERATION |
|
|
PVINPUT(DC) |
|
|
NominalDCVoltage MaximumDCVoltage |
360VDC/450VDC |
|
Start-upVoltage InitialFeedingVoltage |
110VDC/120VDC |
|
MPPVoltageRange |
120VDC~430VDC |
|
NumberofMPPTrackers MaximumInputCurrent |
1/27A |
|
GRIDOUTPUT(AC) |
|
|
NominalOutputVoltage |
220/230/240VAC |
|
OutputVoltageRange |
184-264.5VACor195.5-253VAC(Selectable) |
|
NominalOutputCurrent |
24.3A |
|
ACINPUT |
|
|
ACStart-upVoltage AutoRestartVoltage |
120-140VAC/180VAC |
|
AcceptableInputVoltageRange |
90-280VACor170-280VAC |
|
MaximumACInputCurrent |
40A |
|
BATTERYMODEOUTPUT(AC) |
|
|
NominalOutputVoltage |
220/230/240VAC |
|
Efficiency(DCtoAC) |
93% |
|
BATTERY&CHARGER |
|
|
NominalDCVoltage |
48VDC |
|
MaximumSolarChargingCurrent |
120A |
|
MaximumACChargingCurrent |
120A |
|
MaximumChargingCurrent |
120A |
|
GENERAL |
|
|
PHYSICAL |
|
|
Dimension,DxWxH(mm) |
140x295x468 |
|
NetWeight(kgs) |
12 |
|
INTERACE |
|
|
ParallelFunction |
Yes,9units |
|
CommunicationPort |
USB/RS232/RS485/WIFI/Dry-contact |
|
ENVIRONMENT |
|
|
Humidity |
0~90%RH(Non-condensing) |
|
OperatingTemperature |
-10to50ºC |
